FREE SHIPPING 8" Color LCD Owon MSO8202T 200MHz 2GS/s Digital Storage Oscilloscope DSO Dual channels+ external trigger | Инструменты
История изменения цены
*Текущая стоимость 104 613,10 уже могла изменится. Что бы узнать актуальную цену и проверить наличие товара, нажмите "Добавить в корзину"
| Месяц | Минимальная цена | Макс. стоимость | Цена |
|---|---|---|---|
| Feb-19-2026 | 132859.4 руб. | 135516.8 руб. | 134187.5 руб. |
| Jan-19-2026 | 107751.76 руб. | 109906.3 руб. | 108828.5 руб. |
| Dec-19-2025 | 130766.0 руб. | 133381.97 руб. | 132073.5 руб. |
| Nov-19-2025 | 129720.77 руб. | 132314.78 руб. | 131017 руб. |
| Oct-19-2025 | 103567.12 руб. | 105638.79 руб. | 104602.5 руб. |
| Sep-19-2025 | 127628.5 руб. | 130181.69 руб. | 128904.5 руб. |
| Aug-19-2025 | 126582.8 руб. | 129114.94 руб. | 127848 руб. |
| Jul-19-2025 | 125536.47 руб. | 128047.71 руб. | 126791.5 руб. |
Описание товара
8" Color LCD Owon MSO8202T 200MHz 2GS/s Digital Storage Oscilloscope DSO Dual channels+ external trigger
Customer from following coutry Need to pay extra EMS/DHL/UPS shipping cost,if you accept,please contact us for future information:
Brazil,Russia,Israel,Czech Republic,Poland,Hungary,Croatia,Ukraine,South Africa,Latvia,India,Argentina,Slovenia,Kazakhstan,Estonia,United Arab Emirates,Lithuania,Bulgaria,Romania,Belarus,Saudi Arabia,Colombia,Brunei,Cyprus,Maldives,Uruguay,Serbia and Montenegro,French Polynesia,Macedonia,Serbia,Kuwait,Bahrain,Botswana,Netherlands Antilles,Armenia
Free Shipping -- DHL,UPS,EMS
Description:
8" Color LCD Owon MSO8202T 200MHz 2GS/s Digital Storage Oscilloscope DSO Dual channels+ external trigger
Main Features
- 2 in 1 ( DSO+ LA )
- 8 inch LCD color display
- Supports USB for data transmission to PC
- USB flash disk storage
- 20 automatic measurements
Digital Storage Oscilloscope:
- 25MHz--200MHz bandwidth
- Max up to 2GS/s sample rate
- Autoscale
- FF
Logic analyzer:
- 33MHz--200MHz bandwidth
- Max up to 1GS/s sample rate
- 16 input channels
- Dimension: 370mm(L)×180mm(H)×120mm(W)
- Weight: 2.2kg
Speifications:
|
Model Name |
MSO8202T |
||||
|
Bandwidth |
200MHz |
||||
|
Sample Rate(Real time) |
2GS/s |
||||
|
Rise time |
≤1.7ns |
||||
|
Display |
8.0'' color LCD , TFT screen, 640×480 pixels |
||||
|
Channel |
Dual channels + external trigger |
||||
|
Horizontal scale (s/div) |
1ns/div~100s/div |
||||
|
DC accuracy(Average) |
Average>16:±(3%reading+0.05div) for XV |
||||
|
Vertical Sensitivity |
2mV/div -10V/div |
||||
|
DC Gain Accuracy |
±3% |
||||
|
Vertical resolution (A/D) |
8 bits (2 channels simultaneously) |
||||
|
Interpolation |
(sin x)/x |
||||
|
Max. Input Voltage |
400V ( DC + AC PK-PK ) |
||||
|
Probe attenuation |
1X,10X,100X,1000X |
||||
|
Trigger Mode |
MSO8202T |
||||
|
Edge, Video, Alternate, Pulse, Slope |
|||||
|
Acquisition mode |
Normal, Peak Detect, Average |
||||
|
Record length |
Max.2M points |
||||
|
Waveform storage |
4 waveforms |
||||
|
Automatic Measurement |
Vpp,Vavg,RMS,Frequency,Period,Vmax,Vmin,Vtop,Vbase,Width,Overshoot ,Preshoot |
||||
|
Waveform math |
+, -, ×, ÷,FFT |
||||
|
Power supply |
100-240V ACRMS,50Hz/60Hz,CAT2 |
||||
|
Lissajou’s |
Bandwidth |
200MHz |
|||
|
Phase |
±3 degrees |
||||
|
Communication interface |
USB,Support USB Flash Disk Storage |
||||
|
Fuse |
1A, T grade, 250V |
||||
|
Logic Analyzer specification |
||
|
Model Name |
MSO8202T |
|
|
Sample rate |
20S/s~1GS/s |
|
|
Bandwidth |
200MHz |
|
|
Channels |
16 |
|
|
Record length |
4M/channel |
|
|
Input impedance |
660KΩ±5% // 15±5pF |
|
|
Trigger mode |
Edge trigger, Bus trigger, State trigger, Data alignment trigger, Data width trigger,Distributed queue trigger |
|
|
Trigger position setting |
Pre-trigger, mid-trigger, re-trigger |
|
|
Threshold Voltage |
±6V |
|
|
Input Signal Range |
±30V |
|
|
Data search |
Available |
|
|
Data System |
Binary system, Decimal system, Hex |
|
|
Digital filter |
0,1,2 optional |
|
|
Setting storage |
10 settings |
|
|
USB flash disk storage |
Available |
|
Application
- Design and Debug Circuit function test
- Education and Training
- Idenified signals logic information
- Mixed signal circuit test
********************************************************************************************************************************************************
