100kw yuchai engine diesel generator set |



Сохраните в закладки:

Цена:585 570,17RUB
*Стоимость могла изменится

Количество:


Новое поступление

Характеристики

100kw yuchai engine diesel generator set |

История изменения цены

*Текущая стоимость 585 570,17 уже могла изменится. Что бы узнать актуальную цену и проверить наличие товара, нажмите "Добавить в корзину"

Месяц Минимальная цена Макс. стоимость Цена
Mar-18-2026 696828.78 руб. 731669.61 руб. 714248.5 руб.
Feb-18-2026 690973.78 руб. 725522.12 руб. 708247.5 руб.
Jan-18-2026 579714.52 руб. 608700.20 руб. 594207 руб.
Dec-18-2025 679261.41 руб. 713224.22 руб. 696242.5 руб.
Nov-18-2025 591426.69 руб. 620997.83 руб. 606211.5 руб.
Oct-18-2025 667550.56 руб. 700928.77 руб. 684239 руб.
Sep-18-2025 661694.83 руб. 694779.58 руб. 678236.5 руб.
Aug-18-2025 655838.9 руб. 688630.79 руб. 672234 руб.
Jul-18-2025 649983.54 руб. 682482.63 руб. 666232.5 руб.

Описание товара

100kw yuchai engine diesel generator set |100kw yuchai engine diesel generator set |100kw yuchai engine diesel generator set |100kw yuchai engine diesel generator set |100kw yuchai engine diesel generator set |100kw yuchai engine diesel generator set |100kw yuchai engine diesel generator set |



1、Huaquan 100kw diesel generator set uses Guangxi Yuchai engine, which is safe and environmentally friendly, and has passed CE certification to obtain certification.

2、This diesel generator set has stable performance, reliable and durable, and strong environmental adaptability.

3、Huaquan generator set nationwide warranty, 12 months after the unit has passed the commissioning test or 1000 hours of cumulative operation; whichever comes first.

4、 Huaquan generator sets can meet the personalized needs of customers in different countries and regions, and provide high-quality and reliable power guarantee for the world.

5、The unit has strong adaptability and can be matched with oil, diesel, water jacket, anti-condensation heater, mobile trailer,rainproof shed, etc.

Genearal

Unit model:

HQ100GF

Steady state voltage adjustment rate (%):

≤± 1

Output power:

100KW

Voltage fluctuation rate (%):

≤ ± 0.5

Power factor:

COSΦ = 0.8 (lagging)

Transient voltage adjustment rate (%):

+20 ~-15

Output voltage:

400V / 230V

Voltage stabilization time (s):

≤1

Output current:

180A

Steady state frequency adjustment rate (%):

≤ ± 1

Rated frequency:

50Hz

Frequency fluctuation rate (%):

≤ ± 0.5

Rated speed:

1500rpm

Transient frequency adjustment rate (%):

+ 10 ~ -7

Fuel grade:

(standard) 0 # light diesel (normal temperature)

Frequency stabilization time (S):

≤3

Dimensions:

2580×800×1450(L×W×H mm)

Fuel consumption (100% load):

209g/kW·h

Start mode:

1600kg

Acoustic noise (LP7m):

95dB(A)

Technical parameters of diesel engine

Brand/origin:

Yuchai Engine

Cooling method:

Closed water-cooling

Model:

YC6B155L-D21

Oil supply method:

direct injection

Number of cylinders / Dare to mention structure:

6 / L Type

Speed regulation method:

Mechanical

Bore stroke:

108×125 mm

Intake method:

Natural inhalation

Compression ratio:

17.5:1

Overload capacity:

110%

Weight:

DC 24V Electric start

Speed:

1500rpm

Technical parameters of generator

Brand:

Huaquan Brushless Generator

Protection level:

IP22

Model:

HQF-100

Wiring mode:

Three-phase four-wire, Y-connection

Rated power:

100kW

Adjustment method:

AVR (Automatic Voltage Regulator)

Rated voltage:

400V / 230V

Output frequency:

50Hz

Insulation class:

H class

Output factor:

COSΦ = 0.8 (lag)

Genset standard features

Ø Direct injection internal combustion engine(Diesel);

Ø AC synchronous generator(Single Bearing);

Ø Water Radiator design for 40-45℃ Ambient belt-driven fans and guards;

Ø Generation output air switch、Standard control panel;

Ø Steel common base with shock absorber;

Ø Dry-type air filter fuel filter,oil filter、starting motor、Self-charging alternator;

Ø starter battery and connecting cables;

Ø Industrial 9dB muffler and accessories;

Ø The engine and alternator’s original technical papers,manuals and testing reports ship with GenSet;

Optional accessories(Extra charged)

Ø Engine oil、diesel、water jacket、Anti-condensation heater

Ø Battery floating charger

Ø Self-protection unit/self-starting control panel

Ø Tree-remote control panel

Ø ATS AUTO-loaded transferring screen

Ø Daily fuel tank、Integral fuel tank

Ø Waterproof type(Cabinet)

Ø Mobile trailer(Drip proof)

Ø Mobile trailer(Silent type)
