SMUN S-250-12 110V/220VAC to 250W 12V 20A Power Supply For LED Strip Light | Обустройство дома

---

Model		S-250-12	S-250-15	S-250-24	S-250-48
Output	DC output Voltage	12V	15V	24V	48V
	Voltage tolerance	±1.0%	±1.0%	±1.0%	±1.0%
	Rated Current	20A	15A	10A	5.2A
	Related Power	250w	250w	250w	250w
	Wave&Noise	120mVp-p	120mVp-p	120mVp-p	200mVp-p
	Adjustable range for DC Voltage	±10%	±10%	±10%	±10%
	Set up,rise,hold up time	200ms  100ms  30ms
Input	Voltage Range	85 ~132VAC  170-264VAC  47-63HZ 240-370VDC
	Input Current	4A/115VAC 2A/230VAC
	Efficiency	79%	80%	81%	82%
	AC inrush current	Cold start current  15A/115V 30A /230VAC
	Leakage current	<0.5mA/240VAC
Protection	Overload	Related output power 105-150% start overload protection
		Protection type: cutoff output, recovery after restart power
	Over voltage	13.8V-16.2V	17.2V-20.2V	27.6V-32.4V	55V-64.8V
		Hiccup mode,recovers automatically after fault condition
Environment	Working temp humidity	-10~+60°C 20%~90%RH
	Stor temp, humidity	-20~+85°C 20%~90%RH Non-condensing
Safety	Withstand voltage	I/P-O/P:1.5KVAC  1min
		I/P-FG:1.5KVAC 1min
		O/P-FG:0.5KVAC 1min
Standard	Safety standard	Fit UL1012
	Refer	Design refer to GB4943,UL60950,EN60950
	EMC standard	Design refer to GB9254,EN55022 Class A
Size	size	L215*W115*H50mm
	Package	0.95kg, 16pcs/16kg
