2.Type and specifications:

2.1Electrical schematic and outline drawings:See outline drawings

2.2Drive mode:Constant current chopper drive;

2.3Excitation way:2Phase excitation (2Phase ten-run shot), you can forward and reverse rotation

2.4Steering: PressAB-BC-CD-DAOrder electricity, extending from the shaft end lookC.W

2.5Rated current(Simplex):1.2 A DC

2.6Rated voltage: 12V

2.7Step angle:1.8.

2.8Insulation class:BGrade insulation

3.Parameters:

3.1Working conditions: Ambient temperature:-20~50CEL;Relative humidity:90%MAX; Mounting position: Shaft horizontal or vertical installation.

3.2Test conditions (above parameters measured in the normal test atmospheric conditions)

3.3Winding DC resistance (25CEL):10 10%

3.4Winding inductance:14mH20%

3.5Location torque:12mN.m REF.

3.6Holding torque(Two interlinked rated current):400 mN.m(I=1.2A)

3.7The maximum load starting frequency:1300pps

3.8The maximum no-load operating frequency:1700pps

3.9Temperature:<80K

3.10Step angle accuracy:1.8. 5%

3.11Moment of inertia:38g.cm2

3.12Motor weight: 0.27Kg/PC REF.

3.13Insulation resistance: between the stator core and the terminals cold insulation resistance should be greater than100M (withDC500VMegger).

3.14Dielectric strength:Motor stator core and wiring terminals should be able to withstandAC600V/1SNo breakdown, leakage current is less than1mA.

4Materials, packaging, transportation and storage:

4.1Product complies with EURoHSDirective

4.2Motor package must be solid and reliable,The box should be marked "Handle with Care", "moisture" and other signs,Its design should be consistent with the correspondingGB191Provisions.

4.2..1Packing: Corrugated Box

4.2.2Inner packing: Foam

4.3Transportation: crates or boxes during transportation should be careful gently,Avoid collisions and percussion,With no acid and other corrosive materials together.

4. 4.4Storage: The motor is stored in ambient air-5~+40CEL,Relative humidity 90,Clean, ventilated warehouse, the air must not contain corrosive gas.
